AION Y PLUS

motor

Pure electric 136 horsepower

Pure electric range (km) Ministry of Industry and Information Technology

310

Electric range (km)CLTC

310

Charging time (hours)

Fast charge (%)

Maximum power (kW)

100(136Ps)

Maximum torque (N·m)

176

gearbox

Single-speed transmission for electric vehicles

Length x Width x Height (mm)

4535x1870x1650

Body structure

5 door 5 seat SUV

Maximum speed (km/h)

130

Official 100 km Acceleration time (s)

100km power consumption (kWh/100km)

12.6 kWh

Power equivalent fuel consumption (L/100km)

1.43

Vehicle warranty period

Four years or 150,000 kilometers

body

Length (mm)

4535

Width (mm)

1870

Height (mm)

1650

Wheelbase (mm)

2750

Front wheel base (mm)

1600

Rear wheel base (mm)

1600

Body structure

SUV

Number of doors (each)

5

Door opening mode

Swing door

Number of seats (PCS)

5

Service weight (kg)

1500

Full load weight (kg)

2060

Luggage compartment Capacity (L)

405

motor

Motor description

Pure electric 136 horsepower

Motor type

Permanent magnet/synchronous

Total motor power (kW)

100

Total motor horsepower (Ps)

136

Total motor torque (N·m)

176

Maximum power of front motor (kW)

100

Maximum torque of front motor (N·m)

176

Number of driving motors

Single motor

Motor layout

preposition

Battery/Charging

Battery type

Lithium iron phosphate battery

Battery characteristic technology

Magazine battery

Cell brand

Guo Xuan Gao Ke

Battery pack warranty

Lifetime warranty for the first owner (exemption of liability is subject to official terms)

Battery capacity (kWh)

37.9

Battery energy density (Wh/kg)

Battery charging

low

Fast charge interface

Position of the fast charge interface

Left fender

Position of the slow charge port

Right fender

Battery temperature management system

low

Low temperature heating

low

Liquid cooling

Single pedal mode

low

Standard configuration

Branded self-charging station

low

Standard configuration

VTOL mobile power station function

gearbox

Transmission description

Single-speed transmission for electric vehicles

Shift number

1

Transmission type

Fixed tooth ratio gearbox

Chassis/steering

Driving mode

front-drive

Front suspension form

McPherson type independent suspension

Rear suspension form

Longitudinal torsion beam type non-independent suspension

Steering type

Electric power assist

Car body structure

self-supporting

Wheel/Brake

Front brake type

Ventilated disk type

Rear brake type

Solid disk type

Parking brake type

Electronic parking

Front tire specifications

215/55 R17

Rear tire specifications

215/55 R17

Spare gauge

a.

Non-full size

1000 yuan

Spare tire placement method

a.

Concealed type
